Scott

SPECS:

• Frame: Spark RC Carbon
• Fork: FOX 32 SC Float Factory Air / 100mm travel
• Rear Shock: FOX NUDE EVOL Trunnion / Travel 100-70-Lockout / 165 x 40mm,
• Axles Front: 15 x 110mm axle Rear: 12 x 148mm Boost axle
• Rims/Wheels: Syncros Silverton 1.0 SL CL full carbon, F: 15x110mm, R: 12 x 148mm Boost, 26mm Tubeless ready rim, DT Swiss 190 Hubs with Ratchet
• Tires: Maxxis Rekon Race / 2.35" / 120TPI Kevlar Bead, Tubeless Ready / EXO
• Crankset: SRAM XX1 DUB Eagle Boost Carbon crankarm, QF 168
• Chainrings: 32t
• Bottom Bracket: SRAM DUB PF integrated / shell 41 x 92mm
• Chain: SRAM CN XX1 Eagle
• Rear Derailleur: SRAM XX1 Eagle AXS / 12 Speed, Wireless Electronic Shift System
• Cassette: SRAM XX1 / XG1299 / 10-50t
• Shifters: SRAM Eagle AXS Controller
• Handlebars: Syncros Fraser iC SL Carbon, / 9° / 740mm
• Grips: Syncros Pro lock-on grips
• Brakes: Shimano XTR M9100 Disc, 180/F and 160/R RT-MT900 CL rotor
• Saddle: Syncros Belcarra Regular 1.0, Carbon rails
• Seatpost: Syncros Duncan SL Carbon, 10mm offset / 31.6 x 400mm

SPECS:

• Frame: Genius Carbon, IMP Technology, HMF main frame

• BB92, alloy SL 6011 swingarm

• Fork: FOX 36 Float Rhythm Air Grip3 3-Modes, 15x110mm QR axle, tapered steerer, 44mm offset, reb. adj., lockout, 150mm travel

• Rear Shock: FOX Float EVOL Performance Trunnion, 3-modes, lockout-trail-descend, DPS, 150mm, 185X55mm, Contessa custom tune

• Remote System: SCOTT TwinLoc TSP suspension-seatpost remote, 3-modes, integrated grip clamp

• Rear Derailleur: SRAM NX Eagle, 12spd

• Shifters: SRAM SX Eagle Trigger

• Crankset: SRAM X1 Eagle DUB Boost 30t

• Chainguide: Scott custom

• Bottom Bracket: SRAM DUB PF integrated, shell 41x92mm

• Chain: SRAM CN NX Eagle

• Brakes: Shimano MT520 4 Piston Disc

• Rotor: Shimano SM-RT64 CL / 203/F and 180/R

• Handlebar: Syncros Hixon 2.0, alloy 6061D.B., 12mm rise, 9°, 780mm, Syncros Pro lock-on grips

• H'Stem: Syncros FL2.0, 6061 alloy, 6°, integrated top cap, 31.8mm, 1 1/8"

• Seatpost: Syncros Duncan Dropper Post 2.5 31.6mm / S size 100mm / M size 125mm / L size 150mm

• Seat: Syncros Savona 2.0 (V-Concept) Channel

• Headset: Syncros Pro press-fit E2, tapered 1.5"-1 1/8"

• OD 50/62mm, ID 44/56mm

• Front Hub: Formula CL-811 15x110mm

• Rear Hub: Formula CL-148S Boost 12x148mm

• Spokes: Stainless Black 15G 1.8mm

• Rims: Syncros X-30, 32h, 30mm, sleeve joint, TR

• Front Tire: Maxxis Dissector 2.6" 60TPI Kevlar Bead tubeless-ready EXO

• Rear Tire: Maxxis Rekon 2.6" 60TPI Kevlar Bead tubeless-ready EXO

• Extras: Syncros Trail Fender


SPECS:

• Frame: Genius Carbon, IMP Technology, HMF main frame, BB92, Alloy SL 6011 swingarm, VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj, SW dropouts for Boost 12x148mm, TBC Trunnion box construction

• Fork: FOX 36 Float Performance Elite Air FIT4, 3-Modes with low Speed adj., Kabolt 15x110mm axle, 44mm offset, tapered steerer, Reb. Adj., Lockout, 150mm travel

• Rear Shock: FOX NUDE TR EVOL Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Lockout-Traction Control-Descend, custom Ramp Adjust with linear and progressive settings, DPS, Reb. Adj., travel 150-100-Lockout, 185X55mm

• Remote System:

• SCOTT TwinLoc TSP Technology, Suspension-Seatpost Remote, below Bar, 3 modes, integ. Grip clamp

• Rear Derailleur: Shimano XT RD-M8100 SGS, Shadow Plus, 12-speed

• Shifters: Shimano XT SL-M8100-IR, Rapidfire Plus, Ispec EV clamp

• Crankset: Shimano XT FC-M8100-1, Hollowtech 2, 32t

• Chainguide: SCOTT custom

• Bottom Bracket Set: Shimano SM-BB71-41A, shell 41x92mm

• Chain: Shimano SLX CN-M7100

• Cassette: Shimano XT CS-M8100-12, 10-51t

• Brakes: Shimano XT M8120 4 Piston Disc

• Rotor: Shimano SM-RT76, 6 Bolt, 203/F and 180/R

• Handlebar: Syncros Hixon 1.5, Alloy 7050D.B., 12mm rise, 9°, 780mm Syncros Pro lock-on grips

• H'Stem: Syncros FL1.5, Alloy 2014, integrated spacer & top cap, 31.8mm, 6°, 1 1/8"

• Seatpost: FOX Transfer Performance Elite dropper post, 31.6mm, S size 125mm, M & L size 150mm, XL size 175mm

• Seat: Syncros Tofino 2.0 Regular, CRMO rails

• Headset: Syncros Pro Press Fit E2, Tapered 1.5"-1 1/8", OD 50/62mm, ID 44/56mm

• Wheelset: Syncros Revelstoke 2.0 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm tubeless ready rim 28h, Micro Spline, Syncros Axle w/removable lever with tool

• Tires: Maxxis Dissector, 2.6", 60TPI Foldable, tubeless ready, EXO 3C Maxx Terra

• Extras: Fox 36 Fender


SPECS:

• Frame: Genius Carbon, IMP Technology, HMF Main Frame

• BB92, Alloy SL 6011 swingarm, VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj., SW dropouts for Boost 12x148mm, TBC Trunnion box construction

• Fork: FOX 36 Float Performance Air Grip 3, 3-Modes, Kabolt 15x110mm axle, tapered steerer, 44mm offset, Reb. Adj., Lockout, 150mm travel

• Rear Shock: FOX NUDE T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, custom large air volume, DPS, Reb. Adj., travel 150-100-Lockout, 185X55mm

• Remote System: SCOTT TwinLoc TSP Technology, Suspension-Seatpost Remote, below Bar, 3 modes, integ. Grip clamp

• Rear Derailleur: Shimano XT RD-M8100 SGS, Shadow Plus, 12 speed

• Shifters: Shimano Deore SL-M6100-IR, Rapidfire Plus, Ispec EV clamp

• Crankset: Shimano SLX FC-M7100-1, Hollowtech 2, 32t

• Chainguide: SCOTT custom, BB-SET Shimano BB-MT500, shell 41x92mm

• Chain: Shimano Deore CN-M6100

• Cassette: Shimano Deore CS-M6100-12, 10-51t

• Brakes: Shimano Deore M6120 4 Piston Disc

• Rotor: Shimano SM-RT66, 6 Bolt, 203/F and 180/R

• Handlebar: Syncros Hixon 1.5, Alloy 7050D.B., 12mm rise, 9°, 780mm, Syncros Pro lock-on grips

• H'Stem: Syncros FL1.5, Alloy 2014, integrated Spacer & Top Cap, 31.8mm, 6°, 1 1/8"

• Seatpost: Syncros Duncan Dropper Post 2.0, 31.6mm, S size 100mm, M size 125mm, L & XL size 150mm

• Seat: Syncros Tofino 2.0 Regular CRMO rails

• Headset: Syncros Pro Press Fit E2, Tapered 1.5"-1 1/8", OD 50/62mm, ID 44/56mm

• Wheelset: Syncros Revelstoke 2.5 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm tubeless ready rim 28h, Micro Spline, Syncros Axle w/Removable Lever with tool

• Front Tire: Maxxis Dissector, 2.6", 60TPI Foldable, tubeless ready, EXO 3C Maxx Terra

• Rear Tire: Maxxis Rekon, 2.6", 60TPI foldable, tubeless ready, EXO 3C Maxx Terra

• Extras: Fox 36 Fender


SPECS:

• Frame: Genius Alloy SL 6011, custom butted, VLK Virtual 4 Link kinematic,

• 29", tire compatible with Geo-BB adj., TBC Trunnion box construction, Boost 12x148mm

• Fork: RockShox Revelation RL3 Air, custom charger 3-mode damper, 15x110mm Maxle Lite, 42mm offset, tapered steerer, lockout, Reb. Adj., 150mm travel

• Rear Shock: FOX Float EVOL Performace Trunnion, 3 modes, Lockout-Trail-Descend DPS, Reb. Adj., travel 150mm, 185X55mm

• Remote System: SCOTT TwinLoc TSP, Suspension-Seatpost Remote below bar, 3 modes, integ. grip clamp

• Rear Derailleur: Shimano XT RD-M8100 SGS, Shadow Plus, 12 speed

• Shifters: Shimano Deore SL-M6100-R, Rapidfire Plus

• Crankset: Shimano FC-MT611-1, 32t

• Chainguide: SCOTT custom

• Bottom Bracket Set: Shimano BB-MT500, shell 41x92mm

• Chain: Shimano Deore CN-M6100

• Cassette: Shimano Deore CS-M6100-12, 10-51t

• Brakes: Shimano MT520 4 piston disc

• Rotor: Shimano SM-RT64 CL, 203/F and 180/R

• Handlebar: Syncros Hixon 2.0, Alloy 6061D.B., 12mm rise, 9°, 780mm, Syncros Pro lock-on grips

• H'Stem: Syncros FL2.0, 6061 Alloy, 6°, integrated top cap, 31.8mm, 1 1/8"

• Seatpost: Syncros Duncan Dropper Post 2.5, 31.6mm, S size 100mm, M size 125mm, L & XL size 150mm

• Seat: Syncros Tofino 2.5 regular

• Headset: Syncros Pro Press Fit E2, tapered 1.5"-1 1/8", OD 50/62mm, ID 44/56mm

• Front Hub: Shimano HB-MT410-B CL, 15x110mm

• Rear Hub: Shimano FH-MT410-B CL, 12x148mm, Micro Spline

• Spokes: Stainless, black 15G, 1.8mm

• Rims: Syncros X-30S, 32h, 30mm, Sleeve Joint, tubeless ready

• Front Tire: Maxxis Dissector, 29" x 2.6", 60TPI, foldable, tubeless ready, EXO

• Rear Tire: Maxxis Rekon, 29" x 2.6", 60TPI, foldable, tubeless ready, EXO


SPECS:

• Frame: Genius Alloy SL 6011
• Fork: Marzocchi Z2 Air Rail 3, 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 150mm travel
• Rear Shock: X-Fusion NUDE Trunnion SCOTT custom w. travel/geo adj., 3 modes: Lockout-Traction Control-Descend
• Remote System: SCOTT TwinLoc TSP Technology
• Rear Derailleur: SRAM NX Eagle 12 Speed
• Shifters: SRAM SX Eagle Trigger
• Crankset: SRAM X1 Eagle DUB 32T
• Bottom Bracket: SRAM DUB PF 92 MTB / shell 41x92mm
• Chain: SRAM CN NX Eagle
• Cassette: SRAM SX-PG1210 / 11-50 T
• Brakes: Shimano MT501 Disc
• Rotor: Shimano SM-RT30 CL / 203/F and 180/R
• Handlebars: Syncros Hixon 2.0 / Alloy 6061D.B., 12mm rise / 9° / 780mm, Syncros Pro lock-on grips
• Stem: Syncros FL2.0 / 6061 Alloy 6° / integrated Top Cap / 31.8mm / 1 1/8"
• Seatpost: Syncros Duncan Dropper Post 31.6mm / S size 100mm / M size 130mm / L & XL size 150mm
• Saddle: Syncros Tofino 2.5 Regular
• Headset: Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" OD 50/62mm / ID 44/56mm
• Front Hub: Formula CL-811 / 15x110mm
• Rear Hub: Formula CL-148S / 12x148mm
• Rims: Syncros X-30 / 32H / 30mm
• Front Tire: Maxxis Dissector / 2.6" / 60TPI Foldable Tubeless Ready / EXO
• Rear Tire: Maxxis Rekon / 2.6" / 60TPI Foldable Tubeless Ready / EXO

SPECS:

• Frame: Carbon Main Frame, Alloy swingarm, Virtual 4 link kinematic VLK, 27.5" and 29" compatible, geo adj., Boost 148x12mm, 150mm travel, Bosch Gen4, Integr. removable Battery, tapered headtube E2/Forkstop, central kickstand mount, range booster ready

• Fork: FOX 36 Rhythm Air, 160mm travel, Grip 3, 3-modes, 15x110mm QR axle tapered steerer, Reb. Adj., lockout, 160mm travel

• Rear Shock: FOX Float EVOL Performace Trunnion, 3 modes, Lockout-Trail-Descend, DPS, Reb. Adj., 150mm travel, 185x55mm
• Remote System: SCOTT TwinLoc Suspension System, 3 modes front and rear, integ. Grip clamp

• Drive Unit: Bosch Performance CX, EU: 25kmh, INT: 20mph

• Battery: PowerTube 625Wh

• Display: Bosch Purion

• Charger: 4A Charger

• Rear Derailleur: SRAM NX Eagle / 12 Speed

• Shifters: SRAM SX Eagle Single Click

• Crankset: FSA CK-745 165mm, 34t

• Chainguide: SCOTT custom

• Chainring: SRAM Eagle 34t DM, steel

• Chain: SRAM SX Eagle

• Cassette: SRAM PG1210, 11-50t

• Brakes: Shimano Deore M6120 4-piston disc

• Front Rotor: SM-RT64 CL 203mm

• Rear Rotor: RT-EM600 CL 203mm

• Handlebar: Syncros Hixon 1.5, Alloy 7050D.B., 12mm rise, 9°, 780mm, Syncros Pro lock-on grips

• H'Stem: Syncros FL1.5, 2014 Alloy L-shape spacer & top cap, 31.8mm, 6°, 1 1/8"

• Seat Post: Syncros Duncan Dropper Post 2.5, 31.6mm, S size 100mm, M size 125mm, L size 150mm, XL size 170mm

• Seat: Syncros Tofino 1.5 regular, titanium rails

• Headset: Acros Blocklock, tapered 1.5"-1 1/8", OD 52/62mm, ID 44/56mm
• Front Hub: Formula CL-811, 15x110mm

• Rear Hub: Formula ECT-148S, Boost 148x12mm

• Spokes: Stainless, black

• Rims: Syncros MD30, 32h, 30mm, pin joint, tubeless ready

• Front Tire: Schwalbe MagicMary 29x2.6", Snake Skin, TL-Easy, SuperTrail, Addix Soft

• Rear Tire: Schwalbe Hans Dampf 29x2.6", Snake Skin, TL-Easy, SuperTrail, Addix, Speedgrip

• Lights: Bosch Light Cable pre-installed F&R


SPECS:

• Frame: Carbon main frame an alloy SL 6011 swingarm

• Fork: FOX 38 Float Performance Elite Air, 170mm

• Shock: FOX Nude TR EVOL Trunnion

• Remote System: SCOTT TwinLoc TSP, suspension-seat post remote

• Rear Derailleur: SRAM GX Eagle 12spd

• Shifters: SRAM GX Eagle Trigger

• Crankset: SRAM GX Eagle DUB Boost 32t

• Bottom Bracket: SRAM DUB PF integrated shell 41x92mm

• Chain: SRAM CN GX Eagle

• Cassette: SRAM GX XG1275 10-52t

• Brakes: Shimano XT M8120 4 piston disc

• Rotors: Shimano SM-RT76 6 bolt 203/F and 180/R

• Handlebar: Syncros Hixon 1.5 rise, alloy 20140D.B. 20mm rise, 8°, 780mm, Syncros Pro lock-on grips

• H'Stem: Syncros XM1.5, alloy 6061

• integrated spacer & top cap, 31.8mm, 0°, 1 1/8"

• Seatpost: FOX Transfer Performance Elite dropper post, 31.6mm / S 125mm / M 150mm / L & XL 175mm

• Saddle: Syncros Kaslo 1.5, titanium rails

• Headset: Syncros Pro press-fit E2, tapered 1.5"-1 1/8" OD 50/62mm, ID 44/56mm

• Wheelset: Syncros Revelstoke 2.0, 6 bolt F: 15x110mm, R: 12x148mm boost, 30mm TR rim 28h, XD, Syncros axle w/removable lever with tool

• Front Tire: Maxxis Assegai 2.6" 60tpi foldable EXO TR 3C Maxx Terra

• Rear Tire: Maxxis Dissector 2.6" 120tpi foldable EXO+ TR 3C Maxx Terra

• Extras: Fox 38 Fender


SPECS:

• Frame: Ransom Alloy SL
• Fork: FOX 38 Float Performance Air / Grip 3-Modes / 15x110mm QR axle 44mm offset / tapered steerer Reb. Adj. / Lockout / 170mm travel
• Rear Shock: FOX NUDE T EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend custom large air volume / DPS / Reb. Adj. Travel 170-120-Lockout / 205X65mm
• Remote System: SCOTT TwinLoc TSP Technology Suspension-Seatpost Remote below Bar / 3 modes / integ. Grip clamp
• Rear Derailleur: SRAM NX / Eagle 12 Speed
• Shifters: SRAM NX Eagle Trigger
• Crankset: SRAM NX Eagle DUB Boost 32T
• Bottom Bracket: SRAM DUB PF integrated / shell 41x92mm
• Chain: SRAM CN NX Eagle
• Cassette: SRAM NX / PG1210 / 11-50 T
• Brakes: Shimano M6120 4 Piston Disc
• Rotor: Shimano SM-RT76 / 6 Bolt / 203/F and 180/R
• Handlebars: Syncros Hixon 1.5 Rise / Alloy 20140D.B. 20mm rise / 8° / 780mm Syncros Pro lock-on grips
• Stem: Syncros XM1.5 / Alloy 6061 integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
• Seatpost: Syncros Duncan 2.0 Dropper Post 31.6mm / S 125mm / M 150mm / L & XL 170mm
• Saddle: Syncros Kaslo 2.0 Crmo Rails
• Headset: Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8"
• OD 50/62mm / ID 44/56mm
• Wheels: Syncros Revelstoke 2.5 6 Bolt Front: 15x110mm, Rear: 12x148mm Boost
• 30mm Tubeless ready rim 28Hr
• Syncros Axle w/Removable Lever with Tool
• Front Tire: Maxxis Assegai / 2.6" / 60TPI Foldable / EXO / TR / 3C Maxx Terra
• Rear Tire: Maxxis Dissector / 2.6" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra

SPECS:

• Frame: Spark Carbon HMF Integrated Suspension Technology
• Fork: FOX 34 Float Performance Elite Air FIT4 3-Modes with low Speed adj. / Kabolt 15x110mm axle 44mm offset / tapered steerer / Lockout 130mm travel
• Rear Shock: FOX NUDE 5T EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Custom large Air volume / DPS / Reb. Adj. Travel 120-80-Lockout / T165X45mm
• Bottom Bracket: Shimano SM-BB71-41A / shell 41x92mm
• Headset: Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
• Stem: Syncros DC 1.5 Syncros Cable Integration System 0° rise / 7050 Alloy / 31.8mm / 1 1/8"
• Handlebars: Syncros Fraser 1.5 DC Alloy 7075
• Grips: Syncros Pro lock-on grips
• Saddle: Syncros Tofino 1.5 Regular Titanium rails
• Seatpost: FOX Transfer Performance Elite Dropper Post 31.6mm / S & M size 125mm / L & XL size 150mm
• Rear Derailleur: 12-speed Shimano XT RD-M8100 SGS Shadow Plus
• Crank: Shimano XT FC-M8120-1 / Hollowtech 2 32T
• Shifters: Shimano XT SL-M8120-IR / Rapidfire Plus Ispec EV clamp
• Cassette: Shimano XT CS-M8100-12 / 10-51 T
• Chain: Shimano SLX CN-M7100
• Brakes: Shimano XT M8120 4 Piston Disc

SPECS:

• Frame: Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot, adjustable head angle, Syncros Cable Integration System, BB92, UDH Interface, 12x148mm with 55mm chainline

• Fork: FOX 34 Float Rhythm Air Grip 3, 3-Modes, Kabolt 15x110mm axle, tapered steerer, 44mm offset, Reb. Adj., lockout, 130mm travel

• Rear Shock: FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Lockout-Traction Control-Descend, custom large air volume, DPS, Reb. Adj., travel 120-80-lockout, T165X45mm

• Remote System: SCOTT TwinLoc 2 Technology Suspension & dropper remote

• 3 suspension modes

• Rear Derailleur: Shimano XT RD-M8100 SGS, Shadow Plus, 12 Speed

• Shifters: Shimano Deore SL-M6100-IR, Rapidfire Plus, Ispec EV clamp

• Crankset: Shimano SLX FC-M7120-1, Hollowtech 2, 55mm CL, 32t

• Bottom Bracket Set: Shimano BB-MT500 shell 41x92mm

• Chain: Shimano Deore CN-M6100

• Cassette: Shimano Deore CS-M6100-12 10-51 T

• Brakes: Shimano Deore M6120 4 Piston Disc

• Rotor: Shimano SM-RT64 CL F&R 180mm

• Handlebar: Syncros Fraser 2.0 DC Alloy 6061 D.B. mini Rise, back sweep 8°, 760mm, Syncros Pro lock-on grips

• H'Stem: Syncros DC 2.0, Syncros Cable Integration System 0° rise, 6061 Alloy, 31.8mm, 1 1/8"

• Seatpost: Syncros Duncan dropper post 2.0, 31.6mm, (S-M) 125mm, (L-XL) size 150mm

• Saddle: Syncros Tofino 2.0 regular CRMO rails

• Headset: Syncros - Acros Angle adjust & cable routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB

• Front Hub: Formula CL-811 15x110mm

• Rear Hub: Formula CL-148M, 12x148mm, Micro Spline, Syncros Axle w/removable lever, with 6mm Allen, T30, and T25 tools

• Spokes: Stainless Black 15G 1.8mm

• Rims: Syncros X-30SE, 32h, 30mm, tubeless ready

• Front Tire: Schwalbe Wicked Will 29x2.4" EVO Super Race, TLE, 67EPI, Addix Speed Soft

• Rear Tire: Schwalbe Wicked Will 29x2.4" EVO Super Race TLE 67EPI Addix Speed Grip


SPECS:

• Frame: Spark Alloy SL 6011, Integrated Suspension Technology, flex pivot, adjustable head angle, Syncros Cable Integration System, BB92, UDH Interface, 12x148mm with 55mm chainline

• Fork: RockShox Pike Select RL3 Air, custom charger, 3-Mode damper, 15x110mm Maxle Lite / 42mm offset / Tapered steerer lockout, Reb. Adj., 130mm travel
• Rear Shock: RockShox Deluxe Select RL3 Trunnion, 3 modes, Lockout-Trail-Descend, Debon Air, Reb. Adj., 120mm travel, T165X45mm
• Remote System: SCOTT TwinLoc 2 Technology, suspension & dropper remote, 3 suspension modes

• Rear Derailleur: SRAM GX Eagle 12-speed

• Shifters: SRAM NX Eagle Trigger

• Crankset: SRAM X1 Eagle DUB, 55mm CL, 32t

• Bottom Bracket Set: SRAM DUB PF 92 MTB wide, shell 41x92mm

• Chain: SRAM CN NX Eagle

• Cassette: SRAM SX-PG1210, 11-50t

• Brakes: Shimano MT501 disc

• Rotors: Shimano SM-RT64 CL, F&R 180mm

• Handlebar: Syncros Fraser 2.0 DC Alloy 6061 D.B., mini rise, back sweep 8°, 760mm, Syncros Pro lock-on grips

• H'Stem: Syncros DC 3.0 Syncros Cable Integration System, 0° rise, 6061 Alloy, 31.8mm, 1 1/8"

• Seatpost: Syncros Duncan Dropper Post 2.0, 31.6mm - S & M size 125mm, L & XL size 150mm

• Seat: Syncros Tofino 2.5 Regular

• Headset: Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB

• Front Hub: Formula CL-811 15x110mm

• Rear Hub: Formula CL-148S 12x148mm, Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools

• Spokes: Stainless Black 15G 1.8mm

• Rims: Syncros X-30SE 32h 30mm

• Tires: Schwalbe Wicked Will, 29x2.4" Performance, TLR, foldable, Addix


SPECS:

• Frame: Spark Alloy SL 6011, Integrated Suspension Technology, Flex Pivot, adjustable head angle Syncros Cable Integration System, BB92, UDH Interface, 12x148mm with 55mm chainline

• Fork: RockShox Judy Silver TK Solo Air, 15x110mm QR axle, 42mm offset, tapered steerer, 2-Modes, Reb. Adj., lockout, 130mm travel

• Rear Shock: X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., travel 120-80-lockout, T165X45mm

• Remote System: SCOTT TwinLoc 2 Technology, suspension & dropper remote, 3 Suspension modes

• Rear Derailleur: Shimano XT RD-M8100 SGS, Shadow Plus, 12-speed

• Shifters: Shimano Deore SL-M6100-R, Rapidfire Plus

• Crankset: Shimano FC-MT512-1 55mm CL, 32t

• Bottom Bracket Set: Shimano BB-MT500, shell 41x92mm

• Chain: KMC X12

• Cassette: Shimano Deore CS-M6100-12, 10-51t

• Brakes: Shimano MT501 Disc

• Rotors: Shimano SM-RT54 CL, F&R 180mm

• Handlebar: Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise, back sweep 8°, 760mm, Syncros Pro lock-on grips

• H'Stem: Syncros DC 3.0, Syncros Cable Integration System, 0° rise, 6061 Alloy, 31.8mm, 1 1/8"

• Seatpost: Syncros Duncan Dropper Post 2.5, 31.6mm, S & M size 125mm, L & XL size 150mm

• Seat: Syncros Tofino 2.5 Regular

• Headset: Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB

• Front Hub: Shimano HB-MT410-B CL, 15x110mm

• Rear Hub: Shimano FH-MT410-B CL, 12x148mm, Micro Spline

• Spokes: Stainless Black 15G, 1.8mm

• Rims: Syncros X-30SE, 32h, 30mm

• Tires: Schwalbe Wicked Will, 29x2.4", Performance, TLR, Foldable, Addix


SPECS:

• Frame: Spark Alloy SL 6011, Integrated Suspension Technology, Flex Pivot, adjustable head angle, Syncros Cable Integration System, BB92, UDH Interface, 12x148mm with 55mm chainline
• Fork: RockShox Judy Silver TK Solo Air 15x110mm QR axle, 42mm offset, tapered steerer, 2-modes, Reb. Adj., lockout, 130mm
• Rear Shock: X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 120-80-Lockout, T165X45mm
• Remote System: SCOTT TwinLoc 2 Technology, suspension and dropper remote, 3 suspension modes
• Rear Derailleur: SRAM NX Eagle 12 Speed
• Shifters: SRAM SX Eagle Trigger
• Crankset: SRAM SX Eagle DUB, 55mm CL, 32t
• BB-Set: SRAM DUB PF 92 MTB Wide, shell 41x92mm
• Chain: SRAM CN SX Eagle
• Cassette: SRAM SX-PG1210, 11-50 T
• Brakes: Shimano MT201 Disc
• Rotor: Shimano SM-RT10 CL, F&R 180mm
• Handlebar: Syncros Fraser 2.0 DC Alloy 6061 D.B. mini rise, back sweep 8°, 760mm, Syncros Pro lock-on grips
• H'Stem: Syncros DC 3.0, Syncros Cable Integration System, 0° rise, 6061 Alloy, 31.8mm, 1 1/8"
• Seatpost: Syncros Duncan Dropper Post 2.5, 31.6mm: S & M size 130mm, L & XL size 150mm
• Saddle: Syncros Tofino 2.5 Regular
• Headset: Syncros Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
• Front Hub: Formula CL-811 15x110mm
• Rear Hub: Formula CL-3248 12x148mm
• Spokes: Stainless Black 15G 1.8mm
• Rims: Syncros X-30SE 32h 30mm
• Tires: Schwalbe Wicked Will 29x2.4" Performance TLR Addix

SPECS:

• Frame: Carbon main frame, alloy swingarm, virtual 4 link kinematic VLK, 27.5" and 29" compatible, geo adj., Boost 148x12mm, 140mm, Bosch Gen4, integr. DT battery, tapered headtube E2, central kickstand mount, range booster ready

• Fork: FOX 34 Float Performance Air, eMTB+, FIT4 3-Modes with low-speed adj., 15x110mm QR axle, tapered steerer, Reb. Adj., lockout, 140mm

• Rear Shock: FOX Float EVOL Performance Trunnion, 3 modes, Lockout-Trail-Descend, DPS, Reb. Adj., 140mm, 185x50mm

• Remote System: SCOTT TwinLoc Suspension System, 3 modes front and rear, integ. grip clamp

• Drive Unit: Bosch Performance CX 20mph

• Battery: PowerTube 625Wh

• Display: Bosch Purion

• Charger: 4A charger

• Rear Derailleur: SRAM NX Eagle 12-speed

• Shifters: SRAM SX Eagle single click

• Crankset: FSA CK-745 165mm 34t

• Chainguide: SCOTT custom

• Chainring: SRAM Eagle 34T DM steel

• Chain: SRAM SX Eagle

• Cassette: SRAM PG1210 11-50t

• Brakes: Shimano BR-MT520 4 piston

• Front Rotor: Front: SM-RT64 CL 203mm

• Rear Rotor: RT-EM600 CL 203mm

• Handlebar: Syncros Hixon 1.5 Rise, alloy 2014D.B., 20mm rise, 8°, 760mm, Syncros Comfort lock-on grips

• Stem: Syncros FL1.5 2014 alloy, L-shape spacer & top cap, 31.8mm, 6°, 1 1/8"

• Seatpost: Syncros Duncan Dropper Post 2.5, 31.6mm

• Saddle: Syncros ER1.5 CRMO rails

• Headset: Syncros ER2.0 press fit E2 tapered 1.5"-1 1/8" OD 52/62mm, ID 44/56mm

• Front Hub: Formula CL-811 15x110mm

• Rear Hub: Formula ECT-148M boost 148x12mm

• Spokes: Stainless black

• Rims: Syncros MD30, 32h, 30mm, pin joint, TR

• Front Tire: Maxxis Rekon 29x2.6" 120TPI foldable bead EXO+ TR 3C Maxx Terra

• Rear Tire: Maxxis Rekon 29x2.6" 120TPI foldable bead EXO+ TR 3C Maxx Terra

• Lights: Bosch Light Cable pre-installed F&R

• Extras: Syncros Trail Fender


SPECS:

• Frame: Alloy, Virtual 4 link kinematic VLK, 27.5" and 29" compatible, geo adj., boost 148x12mm, 140mm, Bosch Gen4, Integr. removable battery, tapered headtube E2, central kickstand mount, range booster ready

• Fork: Marzocchi Z2 Air eMTB+, Rail 3, 3-Modes 15x110mm QR axle tapered steerer 44mm offset Reb. Adj. lockout 140mm

• Shock: FOX Float EVOL Performace Trunnion, 3 modes, lockout-Trail-Descend, DPS, Reb. Adj., 140mm, 185x50mm

• Remote System: SCOTT TwinLoc Suspension System, 3 modes front and rear, integ. grip clamp

• Drive Unit: Bosch Performance CX 20mph

• Battery: PowerTube 625Wh

• Display: Bosch Purion

• Charger: 4A charger

• Rear Derailleur: Shimano XT 12-speed

• Shifters: Shimano SL-M6100

• Crankset: SA CK-745 165mm 34t

• Chainring: FSA WB604 34t DM steel

• Chain: Shimano CN-M6100

• Cassette: Shimano CS-M6100 10-51t

• Brakes: Shimano BR-MT520 4 piston

• Front Rotor: SM-RT64 CL 203mm

• Rear Rotor: RT-EM600 CL 203mm

• Handlebar: Syncros Hixon 2.0 rise alloy 6061D.B. 20mm rise, 8°, 760mm, Syncros Comfort lock-on grips

• H'Stem: Syncros FL2.0 6061 alloy, L-Shape spacer & top cap, 31.8mm, 6°, 1 1/8"

• Seatpost: Syncros Duncan Dropper Post 2.5 31.6mm

• Saddle: Syncros ER2.0

• Headset: Syncros ER2.0 Press Fit E2 tapered 1.5"-1 1/8" OD 52/62mm, ID 44/56mm

• Front Hub: Shimano HB-MT410-B CL 15x110mm

• Rear Hub: Shimano FH-MT410-B CL boost 12x148mm

• Spokes: Stainless black

• Rims: Syncros MD30, 32h, 30mm, Pin Joint TR

• Front Tire: Maxxis Rekon 29x2.6" 120TPI foldable bead

• EXO+ TR 3C Maxx Terra

• Rear Tire: Maxxis Rekon 29x2.6" 120TPI foldable bead

• EXO+ TR 3C Maxx Terra

• Lights: Bosch Light Cable pre-installed F&R
