Suspension

Hard-hitting and capable enough to handle the unique rigors of enduro and E-MTB riders alike, Yari features a stiff chassis combined with the DebonAir™ air spring and proven Motion Control™ damper. Yari is the enduro option for those who ride hard on a budget.

Model ID:FS-YARI-RC-B3

FEATURES

• Updated highly-tunable DebonAir air spring offers a buttery smooth feel off the top and maintains a higher ride height for increased confidence in steep terrain
• New graphic package for a fresh, premium look
• Motion Control damping featuring low-speed compression adjustment
• Chassis derived from Lyrik

SPECS

• Wheel Size: 29"
• Travel: 170mm
• Spring: DebonAir, Dual Position Air
• Fork Offset: 42mm (29")
• Maximum Rotor Size: 220mm
• Upper Tube Type: 35mm tapered wall aluminum
• Maximum Tire Width: 81, 82
• Minimum Rotor Size: 160mm, 180mm
• Damper Type: Motion Control
• Volume Reducer: 0/4 Tokens, 1/4 Tokens, 2/5 Tokens, 3/6 Tokens, 4/7 Tokens, 5/7 Tokens
• Color (FS): Diffusion Black, Gloss Black

ZEB features an all-new stiff 38mm chassis designed with a Charger R damper and Maxima Plush Fluid. A whole new breed of fork, designed to challenge whatever limits you find.

Model ID: FS-ZEB-R-A1

FEATURES

• New 38mm chassis for increased stiffness and rider confidence
• Charger Technology -- The New Charger™ R damper features factory-tuned compression with easy to adjust rebound
• Highly-tunable DebonAir™ air spring offers a buttery smooth feel off the top and maintains a higher ride height for increased confidence in steep terrain
• Maxima Plush damping fluid reduces friction and silences damper noise
• Short fender compatible (RockShox fender sold separately)
• eMTB endorsement decal

SPECS

• Wheel Size: 27.5", 29"
• Travel (mm): 150mm, 160mm, 170mm, 180mm, 190mm
• Spring: DebonAir, Dual Position Air
• Fork Offset: 38mm (27.5"), 44mm (27.5"), 44mm (29"), 51mm (29")
• Maximum Rotor Size: 220mm
• Upper Tube Type: 38mm aluminum
• Maximum Width (mm): 81
• Minimum Rotor Size (mm): 200
• Damper Type: Charger R
• Volume Reducer: 0/4 Tokens, 1/4 Tokens, 2/5 Tokens
• Color (FS): Diffusion Black, Gloss Black
• Fender Compatibility: Short, 3 point mount
• Weight (g): 2231
• Weight is based on 29" Maxle Stealth 190mm Travel 1.5" Taper Steerer

Yari brings Pike's and the Lyrik's acclaimed look and proven features to a wider audience as an entry point to a 35-millimeter chassis.

FEATURES

• 35mm chassis
• The new refined Motion Control IS damper features Rapid Recovery rebound and its high-speed compression circuit is tuned to match the feeling of the Charger damper
• Fast Black coating on the upper tubes provides improved durability and decreased friction

SPECS

• Positive Spring: Air
• Wheel Size: 29"
• Brake Type: Post Mount 180
• Crown Race: 40
• External Adjustments: Low-Speed Compression Damping , Rebound Damping
• Negative Spring: Air
• Stanchion Diameter: 35
• Steerer Type: Tapered
• Maximum Tire Width: 81
• Offset: 42
• Color: Gloss Black
• Steerer Tube Length (mm): 265
• Front Axle: 15mm Thru x 110mm
• S.H.I.S. Stem Clamp Diameter: 28.6
• Travel (mm): 160
• Axle to Crown Length: 571
• Lockout Switch: Crown
• Weight: 2194g

ZEB is built with a stout 38-millimeter chassis and features the updated DebonAir™ air spring with the performance of the Charger™ R damper. SKF wiper seals and Maxima Plush fluid reduce friction, silences noise, and provides all-around lasting performance.

FEATURES

• Price point Charger™ R cartridge damper featuring an easy to adjust rebound only damper
• Large 38mm chassis for increased stiffness and rider confidence
• Updated highly tunable DebonAir™ air spring offers a buttery smooth feel off the top and maintains a higher ride height for increased confidence in steep terrain
• Ultra-low friction SKF wiper seals provide long-lasting fork performance and improve overall suspension feel
• Maxima Plush damping fluid reduces friction and silences damper noise

SPECS

• Positive Spring: Air
• Wheel Size: 29"
• Brake Type: Post Mount 200
• Crown Race: 40
• External Adjustments: Rebound Damping
• Negative Spring: Air
• Stanchion Diameter: 38
• Steerer Type: Tapered
• Maximum Tire Width: 81
• Offset: 44
• Color: Gloss Black
• Front Axle: 15mm Thru x 110mm
• S.H.I.S. Stem Clamp Diameter: 28.6
• Travel (mm): 170
• Axle to Crown Length: 586
• Designed for ebike: Yes
• Lockout Switch: Crown
• Weight: 2248g

RockShox 38mm Fork Seal Kit Parts for ZEB forks (A+/2021+), includes flangeless ultra-low friction SKF 6mm foam rings .

Volume tuning kits for Fox rear suspension.

The Fox Dust Wiper Kit works with Fox's ultra-smooth Kashima coating to make Fox forks some of the smoothest-functioning in the industry. Unfortunately, dirt can eventually cause the seals to leak and will need to be replaced when the fork is overhauled.

Fox partnered with legendary seal manufacturer SKF to develop its slow-friction fork seals. They are an important first line of defense in keeping your fork functioning smoothly.

• Designed with SKF
• Kit contains dust seals, lower seals, and crush washer

Fox Dust Wipers are standard equipment on Fox suspension forks and are what help give your fork a smooth feel. They help protect your fork internals from dust and grime. This is a replacement part.

With optimized material concentrated at the brace and seal area, outstanding stiffness and steering precision, axle spec of either 9QR, 15x100-millimeters, and available eMTB configured fork options with fender mounting points, Recon Silver is an all-around performer suited for any MTB or eMTB bike.

FEATURES

• eMTB endorsement options with short and full fender mounts are appropriate for all e-bikes (15x110mm)
• Motion Control™ damping featuring Low-Speed Compression adjustment to lockout
• Fast Black finished 32mm steel upper tubes match significant stiffness with a premium look
• 15x110mm versions fit tires up to 2.8" without fenders - use of a full fender will reduce tire clearance

SPECS

• Wheel Size: 29"
• Travel: 100mm
• Spring: Solo Air
• Fork Offset: 51mm
• Maximum Rotor Size: 220mm
• Upper Tube Type: 32mm straight wall steel
• Maximum Tire Width: 81mm
• Minimum Rotor Size: 60mm
• Damper Type: Motion Control
• Color (FS): Diffusion Black, Gloss Black
• Fender Compatibility: Full or Short, 3 point and 2 point mounts, n/a
• Model ID: FS-RCNS-RL-D1

Yari brings the Pike's and the Lyrik's acclaimed look and proven features to a wider audience as an entry point to a 35mm chassis.

SPECS:

• Wheel Size: 27.5"
• Travel (mm): 170mm
• Spring: DebonAir
• Fork Offset:  46mm (27.5")
• Max Rotor Size: 220mm
• Upper Tube Type: 35mm tapered wall aluminum
• Max Tire Width (mm): 81
• Minimum Rotor Size: 180mm
• Damper Type: Motion Control

This kit is for a 2016-2021 32mm/34mm Fork Dust Wiper Replacement.

Required Parts:
025-03-010 Oil: AM, FOX Bath Oil [32 oz.], 20 WT Gold
803-00-944 Kit: Dust Wiper, Forx, 32mm, Low Friction, No Flange
803-00-945 Kit: Dust Wiper, Forx, 34mm, Low Friction, No Flange
Required Tools
398-00-681 2002-017 32 Damper-side and ALL 32-34-36-40 Spring-side Removal Tool
398-00-682 2005-017 34-36-40 Damper-side Removal Tool
398-00-770 Tooling: Guided Fork Seal Driver, One Piece Seal/Wiper, 32
398-00-771 Tooling: Guided Fork Seal Driver, One Piece Seal/Wiper, 34
Supplies Needed
10mm Socket
15mm Socket
2mm Hex Wrench
Mallet
Ratchet
Shock pump
Torque Wrench
Wooden or Plastic Dowel 1" (25.4mm)

For exact instructions visit FOX's website at https://www.ridefox.com/fox17/help.php?m=bike&id=622

ZEB features an all-new stiff 38mm chassis designed with the New Charger R damper, SKF Wiper Seals, and Maxima Plush Fluid. A whole new breed of fork, designed to challenge whatever limits you find.

FEATURES:

• New 38mm chassis for increased stiffness and rider confidence
• Charger Technology – The New Charger™ R damper features factory-tuned compression with easy to adjust rebound
• Highly-tunable DebonAir™ air spring offers a buttery smooth feel off the top and maintains a higher ride height for increased confidence in steep terrain
• Ultra-low friction SKF wiper seals provide long-lasting fork performance and improve overall suspension feel
• Maxima Plush damping fluid reduces friction and silences damper noise
• Short fender compatible (RockShox fender sold separately)
• eMTB endorsement decal

SPECS:

• WHEEL SIZE: 29"
• TRAVEL: 180mm
• SPRING: DebonAir
• FORK OFFSET:  44mm
• MAXIMUM ROTOR SIZE: 220mm
• UPPER TUBE TYPE: 38mm aluminum
• MAX TIRE WIDTH (MM): 81
• MINIMUM ROTOR SIZE: 200mm
• DAMPER TYPE: Charger R
• COLOR: Diffusion Black
• FENDER COMPATIBILITY: Short, 3 point mount
